Dongfeng Small Vacuum Sewage Truck

DONGFENG Small vacuum sewage truck is introduced

Name of vehicle manufacturer

Clw

Vehicle brand/vehicle name

dongfeng

Breakdown truck

Body color

Optional

Engine brand

yuchai Power

Horsepower

130 horsepower

Type of fuel

Diesel fuel

Displacement and power (ml/kw)

2800

95

Emission standards

Optional

Vehicle size

5998*2100*2650mm

Number of tyres

6

Tire specifications

7.00R16LT 16PR

Wheelbase（mm）

3308（Optional）

Number of axes

2

Form of steering

The steering wheel

Total mass (kg)

7630

Quality of equipment(kg)

4150

Number of persons allowed to ride in the cab (person)

2

Maximum design speed (km/h)

90

Euro 3 Dongfeng small Dorika suction truck is introduced as follows:

1. Sewage Truck chassis and appearance

• Chassis: Dongfeng small Dorika chassis, stable performance, moderate bearing capacity, can adapt to urban roads and general complex road conditions.
• Appearance: Compact body size, simple appearance, usually white or engineering yellow and other eye-catching colors, easy to identify in the job.

2. Vacuum Sewer Truck tank and jacket configuration

• Tank: The material of the tank is generally high-quality carbon steel, and stainless steel and other materials can be selected according to demand. The volume is usually about 2-5 square, and the anti-wave plate is set inside the tank, which can reduce the influence of liquid sloshing on the stability of the vehicle during transportation.
• Top: equipped with force extractor, drive shaft, vacuum suction pump and other special equipment. The suction of the vacuum sewage pump is large, the time of pumping the sewage tank is short, and the suction range can reach about 7-8 meters.

3. Sewage Suction Truck performance characteristics

• Strong suction capacity: It can effectively pump sewage and sludge in sewers, septic tanks, etc., and can also pump large solid debris such as stones and bricks.
• Self-suction and self-discharge: the sewage sludge can be inhaled by itself, and the sewage can be discharged by its own pressure or auxiliary equipment after filling, and the operation is simple.

4. Sewer Septic Truck Application scenario

• Widely used in urban sanitation, municipal engineering, residential property, rural environmental sanitation and other fields, for cleaning sewage, septic tanks, sewage Wells and other places of sewage and sludge.
