Parameter Configuration of DONGFENG 8cbm Sewage Suction Truck

Vehicle Brand/Vehicle Name

Ace Sewage Suction Truck

Engine Brand

Yuchai Power

Horsepower

160 horsepower

Type of Fuel

Diesel fuel

Displacement and Power (ml/kw)

2970 / 118

Vehicle Size

7360*2360*3140mm

Tank Volume

8m³

Number of Tyres

6

Tire Specifications

8.25R20

Wheelbase (mm)

3800 (Optional)

Form of Steering

Steering Wheel

Total Mass (kg)

1400kg

Quality of Equipment (kg)

8300kg

Configuration of Tank Body Parameters

The water tank adopts the national standard 4mm thick carbon steel plate, the high-pressure cleaning part adopts the new product Fuuv215 flow rate, 20MPa high-pressure pump, 60m diameter 19 high-pressure pipe. The tank is made of national standard 5mm thick carbon steel plate, standard equipped with Shandong SK-9 full-sealed water circulation pump, anti-overflow valve, according to the manure pipe, with an 8m suction pipe with a quick joint of Yin and Yang End, the back cover is opened by hydraulic pressure.

Dongfeng 8cbm Sewage Suction vehicle Parameter Configuration:

1. Vacuum Sewer Truck Chassis Configuration

• Chassis model: Common EQ1125SJ8CDC, Dongfeng Capt k7, etc.
• Engine: Chochai CY4SK261, Okchai 165 HP, Unnai 150 or 170 HP, Chochai 163 or 170 HP, and other engines.
• Transmission: Equipped with more than 10,000 li six-speed transmission.
• Wheelbase: Generally 3800mm.
• Tire specifications: Such as 245/70R19.5 vacuum tires, 8.25R20, etc.

2. Sewer Septic Truck Top Configuration

• Tank volume: About 8 cubic meters.
• Tank material: 6mm thick Q235 carbon steel plate or Wisco high-quality steel plate.
• Suction pump: Shandong SK-9, SK-12 water circulation pump or Yifeng 10-ton vacuum pump, etc.
• Tank size: Such as diameter 1.5m, length 4.2m or so.
• Discharge mode: Mid-top self-discharge, pressure discharge.

3. Sewage Truck Performance Parameters

• Vertical suction: ≥8 m.
• Full time: < 10 minutes.
• Empty time: < 5 minutes.
• Total weight: About 11995kg.
• Rated load weight: About 4300-9420kg.
• Maintenance quality: About 5640-7500kg.

4. Septic Tank Truck Other Configurations

• Standard: Equipped with vacuum pressure gauge, fecal window, hand washing device, etc.
• Optional: Some vehicles can be equipped with sprinkling, high-pressure cleaning, and other functions to achieve a multi-purpose car.
