Introduction to Isuzu 32 Meter Telescopic Arm Aerial Work Vehicle

Description of the configuration

Basic function and configuration

Basic function and safety configuration of 33M high-altitude work vehicle: work vehicle can achieve platform load of 200KG, maximum work height of 28m, maximum work range of 33m.

Isuzu 33 meters aerial work vehicle related introduction:

1. Bucket Truck chassis configuration

• Model and power: Chassis model is jxw1040cdj2, equipped with Jiangxi Isuzu je493zlq6k engine, power 93kw, 126 HP.
• Cab and accessories: Equipped with 1880 cab, can accommodate 3 people, with air brake, anti-overspeed sound alarm and other functions, external rearview mirror heating, electric Windows, central control lock and other convenient configuration, but also with multi-functional steering wheel, reverse radar, cruise control and other convenient configuration.

2. Configuration of the Insulated Bucket Truck

• Working arm: More than seven sections of the octagonal arm, with synchronous telescopic function, can be rotated 360 degrees.
• Legs: Front V back V double section hydraulic legs, individually adjustable, front and back leg span of about 6 meters.
• Hanging basket: 1.6m stainless steel hanging basket, load 200 kg.
• Operation and control: standard power distribution control operation screen and remote control, some optional oil and electric dual-purpose devices, reverse video, etc., can also be operated by mobile or electronically controlled ground wireless remote control.

3. Telescopic Bucket Truck performance characteristics

• Working height and amplitude: the maximum working height is 33 meters, and the maximum working amplitude is 15 meters and above.
• Operation flexibility: the working arm can be flexibly telescoped, rotated and varied. Some models adopt electro-hydraulic proportional valves, which can realize stepless speed regulation and smooth operation.

4. aerial bucket truck security guarantee

• Limit and interlock: equipped with on-off interlock device, leg support state detection device, etc., to prevent misoperation.
• Emergency system: equipped with emergency power source, such as manual emergency pump, can be emergency in case of failure of the main pump.

5. Application scope of Aerial work vehicle

Suitable for power maintenance, street lamp maintenance, building exterior wall construction, advertising installation, fire rescue and film shooting and other high-altitude work fields.
