12-ton Sprinkler Truck by Cheng Li

Cheng Li 10 Tons Sprinkler Truck Parameters Configuration

1. Water Tank Truck Chassis Configuration:

• Wheelbase: 3950mm
• Engine: Yuchai YCY30170-60
• Cab: New design, white exterior, red-brown interior
• Transmission: Fast small eight-speed with force lifter
• Axles: 2.8t front axle / 8t rear axle
• Tires: 9.00 steel tires
• Features: Air conditioning, airbag seat, central control, multi-functional steering wheel, travel recorder

2. water sprinkler truck Top Configuration:

• 12 Square Meter Water Tank
• Material: Tank Body - Q235 Steel
• Partition Thickness: 3mm
• Tank Body Thickness: 4mm
• Head Thickness: 4mm
• Large Diameter Ball Valve
• Aluminum Alloy Tee
• Main Pipe Thickness: 76mm
• Optional Cast Aluminum Fittings: Aluminum Alloy Elbow Tee, Aluminum Alloy Flange Tee, Aluminum Alloy Pump Outlet Four, Aluminum Alloy Pump Import Through
• Molded Design: One-Time Die Casting, No Welds, Avoids Water Leakage
• Standardized Design for Interchangeability
• Lightweight, Aesthetic, Practical, Enhances Product Grade

Sprinkler Truck Other Accessories:

• Aluminum Aftershower
• Stainless Steel Ball Valve
• High-Pressure Water Cannon
• Punching Plate Platform: 2mm Punching Plate
• Features: Better Anti-Slip, No Water on Platform
• Structure Optimization, Stamping Design
• Lightweight, Aesthetic, Practical, Enhances Product Grade

Special Features of the water truck:

• Forward (Spray) After Sprinkling
• Side Spray Functionality
• After Working Platform Installed with Green Sprinkler High-Pressure Cannon
• Gun Spray Shape Adjustable: Direct Injection, Heavy Rain, Moderate Rain, Drizzle
• Continuous Adjustment Possible
• Maximum Range: Up to 30 Meters
• Equipped with High-Power Special Sprinkler Pump
• Fire Protection Joint
• Flow Valve
• Self-Priming Function
• Filter Included
• Suction Depth: ≥6 Meters
• Sprinkling Width: ≥16 Meters
• Range: ≥30 Meters
• Fogging Range: ≥15 Meters
