DONGFENG Big Dorika 12cbm Sprinkler Truck Introduction

Dongfeng Dorika 12-cubic-meter sprinkler trucks, exemplified by the D9 model, feature the following characteristics:

• Chassis Configuration:
• Strong Power: Equipped with either the Dongfeng Cummins D4.0NS6B195 engine (195 horsepower) or B6.2NS6B230 engine (230 horsepower), paired with a fast 8-speed transmission for full power output, adaptable to various road conditions.
• Good Bearing Capacity: Front axle load of 3.9 tons, rear axle load of 8 tons, wheelbase of 3950mm, 9.00 or 10.00 steel wire tires; some models come with Dongfeng Dana maintenance-free rear axles for enhanced load-bearing capacity and vehicle stability.
• High Comfort: A 2315mm wide cab provides ample interior space, equipped with original air conditioning, heating, central control locks, electric windows and doors, dashcams, directional assistance, and more. Some models offer airbag seats and sleepers to enhance driving comfort.

• Top Configuration:
• Tank Body: Made from 4mm Q235 carbon steel, with a volume of 12 cubic meters. The tank body features a double partition to prevent waves, and has holes at the bottom. After high-pressure gas leak testing, it ensures high strength and a stable center of gravity.
• Water Pump: Equipped with a 60/90 high-power sprinkler pump, capable of self-suction and self-discharge, with large flow and pressure, allowing continuous spraying for approximately 8 hours.
• Spraying System: Standard equipment includes front flushing, rear spraying, side spraying, and a green anti-aircraft gun. The front spray rinse width exceeds 16 meters, the side spray water width exceeds 12 meters, and the rear water cannon range exceeds 30 meters, meeting diverse spraying requirements across different scenarios.

• Street Sprinkler Performance:
• Multiple Functions: This vehicle is not only used for road sprinkling and landscaping irrigation but also for dust suppression at construction sites and emergency firefighting. Different accessories enable a variety of functions.
• Easy Operation: Control switches for each spraying function are centralized in the cab, using pneumatic or electric control for ease of use.
• Safe and Reliable: The vehicle is equipped with ABS and air brakes, with a sturdy upper pipe connection. It uses large-diameter ball valves and new thickened PTFE flange gaskets to prevent water leakage, enhancing the safety and reliability of the vehicle.
