Isuzu 10-ton Refrigerated Truck Introduction

Isuzu 6.8m Box Refrigerated Truck Introduction:

• Engine: Common models include 4HK1-TC60 and others. For example, an Isuzu refrigerated truck equipped with this type of engine has a displacement of 5.1L, a rated power of 151kW, and a maximum torque of 850N·m, providing strong power to meet the needs of Refrigerated Trucks under various road conditions.
• Transmission: Generally equipped with five-speed or six-speed transmissions, such as MSB five-speed transmission and Isuzu MLD six-speed transmission, ensuring smooth shifting and high transmission efficiency.
• Wheelbase: Mostly around 5550mm. The reasonable wheelbase design enhances vehicle stability while providing a better load-bearing foundation for the box.
• Tires: Typically uses 295/80R22.5 and other specifications, featuring strong load-bearing capacity, excellent wear resistance, and the ability to adapt to various complex road conditions.

2. Isuzu Refrigerated Truck Box Configuration:

• Size: The box length is generally about 6.8 meters, the width is approximately 2.3-2.45 meters, and the height is about 2-2.5 meters, offering ample cold storage space to accommodate different types of goods.
• Material: Uses internal and external glass fiber reinforced plastic with an intermediate high-density polyurethane insulation layer, meeting the national A-level insulation standard to effectively reduce cold loss and maintain stable temperatures inside the box.
• Manufacturing Process: Manufactured using a hydraulic adsorption integrated molding production line, ensuring high strength, good sealing, and protection against rain, dust, and other external factors from entering the box and affecting cargo quality.
• Accessories: Features aluminum alloy profiles around the body, stainless steel corners, and stainless steel door locks, hinges, and frames that are durable and rust-resistant. The interior is also equipped with energy-saving LED lighting for convenient loading and unloading at night.

3. Refrigeration System: Different brands and models of refrigeration units can be selected based on user needs, with a temperature adjustment range typically between -20°C and +20°C. This meets the transportation requirements of various refrigerated goods, such as domestic Kelly refrigeration units (-5°C, -15°C options) and imported Carrier 1050 independent chillers.

4. Refrigerated Vehicle Performance:

• Loading Capacity: The rated load mass is generally about 10 tons, with a total mass of around 18 tons, suitable for transporting medium to large quantities of refrigerated goods.
• Maximum Speed: Up to 110 km/h, enabling quick and efficient delivery of goods to their destination.
• Comfort: Some models come equipped with features like single-row cab, air conditioning, power steering, power windows, cruise control, and multi-functional steering wheels, providing a comfortable driving experience for the driver.
• Safety: Equipped with dual-circuit oil brakes, ABS, reversible cab, and air brakes, improving overall vehicle safety.
