HOWO Road Sweeper Truck Cleaning Truck Parameter Configuration

Item

Main Performance Parameters

• Emission Standard: Euro6
• Engine:
• Host Machine: Chassis engine model and manufacturer: Weichai 220 horsepower
• Power (kW): 161
• Horse-power (ps): 220
• Displacement (ml): 4600

Vehicle Basic Argument

• Overall Dimensions (L × W × H) mm: 8550 × 2480 × 3130
• Tyre: 275/80R22.5 18PR, 10.00R20 18PR
• Number of Tires: 7 (including 1 spare)
• Rated Load Mass (kg): 5345
• Quality of Service (kg): 12460
• Maximum Total Mass (kg): 18000

Cleaning vehicle is a kind of sanitation vehicle used for Road Cleaning, mainly introduced as follows:

1. Chassis and Power
   • Chassis type: Mostly adopt Dongfeng, Isuzu, Jianghuai and other second-class chassis restructuring, there are also self-developed integrated special chassis like Sany environment pure electric low-entry cleaning car.
   • Power source: There are auxiliary engine drive, but also pure electric drive, such as Ruiqing S26 pure electric road sweeper.

2. Main Structure of Road Sweeper Truck
   • Includes automobile chassis or new energy vehicle chassis, auxiliary engine or auxiliary motor, carriage, hydraulic valve set, brush drive motor, hydraulic system filter, electronic control system, vortex pump, cleaning device, suction fan, middle sweep brush, rear suction cup, stainless steel dustbin and water tank, diversion trough and large area filter, reversing and sweeping disk image, warning device.

3. Sweeping Truck's Working Principle
   • The middle sweep brush is used to rotate the road garbage, while the middle or rear suction cup uses the negative pressure generated by the fan to suck the garbage into the dustbin; High pressure water pump produces high pressure water, through the spray rod and nozzle to wash the road, the washed sewage and garbage are sucked into the garbage bin.

4. Functional Features
   • Multi-functional operation: It integrates the functions of road sweeping, high pressure washing, spray dust removal, garbage collection and sewage recycling, and can realize a variety of operations such as road cleaning, washing, and curb cleaning.
   • Efficient cleaning: Centralized operation devices such as middle vertical sweep and middle wide suction nozzle, continuous and smooth operation such as scrubbing, washing and absorbing sewage, less splash, high sewage absorption rate, large cleaning width and high efficiency.

5. Road Sweeper Application Scenarios
   • It is widely used in the cleaning of urban main road, viaduct, city square, airport pavement and other places.

6. Advantages of Washing and Sweeping Vehicles
   • Good cleaning effect: High pressure water rinse and brush together, can thoroughly clean road stains and dust, reduce dust.
   • Improve operation efficiency: Complete multiple tasks in one operation, reduce vehicle roundtrip, and improve road cleaning efficiency.
