Cheng Li Small Ice Cream Truck Parameter Settings

Vehicle Details

• Vehicle Brand/Vehicle Name: ace
• Mobile Ice Cream Truck:

Engine Details

• Engine Brand: dongan Power
• Horsepower: 115 horsepower
• Type of Fuel: Gasoline fuel
• Displacement and Power: 1498 ml / 115 kW

Vehicle Dimensions

• Vehicle Size: 4920x1700x2475mm
• Cargo Compartment Dimensions: 2960x1630x1800mm

Other Specifications

• Leaf Springs: -/4+2
• Number of Tyres: 4
• Tire Specifications: 175/70R14C
• Wheelbase: 3050 mm (Optional)
• Number of Axes: 2
• Steering Form: Steering Wheel
• Total Mass: 2040 KG
• Equipment Quality: 1360 KG
• Allowed Number of Riders: 2
• Maximum Design Speed: 100 km/h

Small Food Truck Features

1. Appearance Design of Ice Cream Truck:
   • Body Color Matching: Bright colors like yellow and white.
   • Front Face Design: Long and narrow combined lights, split chrome-plated grille and bumper.
   • Overall Size: Length: 4660mm, Width: 1882mm, Height: 2575mm, Cargo Box Length: 2600mm, Width: 1730mm, Height: 1820mm.

2. Catering Vehicle Performance:
   • Power System: 1.3L naturally aspirated engine (98 HP), 1.5L gasoline engine (116 HP).
   • Handling: Power steering, electric window lift, McPherson independent suspension.

3. Cooking Truck Compartment Design:
   • Interior Space: Approximately 8 cubic meters.
   • Lighting and Sockets: LED lights and sockets for electrical equipment.
   • Floor Material: Aluminum alloy, non-slip pattern.

4. Functional Features of Food Truck:
   • Strong Mobility: Can be on the blue card, no city travel restrictions.
   • Multipurpose: Configurable with ice cream machines, beverage machines, and refrigerators.
   • Advertising: Exterior spray advertising, advertising broadcast system for instant promotion.

5. Dining Truck Cab Configuration:
   • Interior Style: Grey and black, solid two-seater layout.
   • Instrument Panel: Classic barrel type with silver metal inlay.

6. Sales Truck After-Sales Guarantee:
   • Warranty Policy: Some models built on the Chery technology platform offer 6-year / 200,000 km warranty and 10-year / 1 million km engine repair.
