DONGFENG 21cbm Fuel Tank Truck Parameter Configuration

Basic Parameters of the Vehicle

Introduction of Dongfeng 21cbm Tank Truck Models

• 1. Dongfeng Jincheng 6x4 21cbm Tank Truck
• Chassis Configuration: Equipped with Guo Liu Yuzai 270-horsepower engine, Shaan-gear 8-speed with high and low gear transmission, 220-liter aluminum alloy large fuel tank, 295 vacuum explosion-proof tire, stop air brake, total weight 26 tons, rated load 14.07 tons, complete mass 11.8 tons, vehicle length 10000mm, width 2550mm, height 3350mm.
• Top Configuration: Tank volume 21m³, with European standard tank mouth, submarine valve, lower oil port and oil recovery, 5km emergency cut-off valve alarm system, self-priming self-discharge oil pump, can be operated or large flow diesel version refueling machine and 15m automatic return reel, oil gun, equipped with two 5kg fire extinguishers, anti-static belt.
• Cab Configuration: Large cab space, with multi-functional steering wheel, electric glass, four seasons universal fabric seats, air bag seats, original air conditioning, central control platform atmosphere, easy to operate.
• 2. Dongfeng D9 20-ton Oil Tank Truck
• Chassis Configuration: Cummins 230 HP engine, Fast 8-speed with high and low gear transmission, 275 vacuum tires.
• Top Configuration: Tank volume 21m³, rated load mass about 20 tons, tank and related parts meet the standard configuration of the tank truck, specific details can consult the manufacturer.
• 3. Cheng Liwei Brand Dongfeng 21cbm Mobile Refueling Truck
• Chassis Configuration: Dongfeng EQ1250GFJ4 chassis, Dongfeng Cummins ISB21040 engine, 8JS85E transmission, 10.00R20 tires, wheelbase 4350+1300mm and other options, total mass 24400kg, reassembly mass 10205kg, speed 80km/h.
• Top Configuration: Effective volume of the tank is 21 cubic meters, overall size of the tank is 7200×2380×1580mm, transport medium is gasoline, equipped with a variety of refueling device models for choice, tank and vehicle meet the relevant standards for dangerous goods transport.
• 4. Dongfeng Tianlong Rear Eight Wheel 21cbm Fuel Tank Truck
• Chassis Configuration: Total mass 26 tons, load 14 tons, full load 18 tons, repair mass 11.8 tons.
• Top Configuration: Tank volume 21 cubic meters, tank material and specific configuration can be customized according to demand.
• Dongfeng Jincheng V6P 21 Square Tank Truck
• Chassis Configuration: Equipped with 300 HP Weichai engine, Fast 10-speed transmission, 295 vacuum tires, double girder, 13 tons Dana bridge.
• Top Configuration: The tank is made of Hailimeida carbon steel, with a total length of 6.9 meters and a total capacity of 21 square meters.
