Cheng Li 25 Tons Dump Truck Parameter Settings

Cheng Li Dump Truck Configuration

Chassis Section

• Complete Vehicle Model: Cl3255BDFA6
• Chassis Type: CL1255LDJ6
• Vehicle Size: 8100*2550*2700mm
• Total Mass: 25000kg
• Load Mass: 15320kg
• Curb Weight: 9550kg
• Wheelbase: 4350+1350mm
• Horse-Power: 350HP
• Displacement: 7698ml
• Number of Tires: 10
• Tyre Specification: 12.00R20

Top Part

• Container Size: 5600*2200*600mm
• Container Material: High strength carbon steel, side 3 bottom 5 engineering cargo box (cargo box steel plate thickness is optional)
• Lifting Part: China high quality front hydraulic top

Chengli 6x4 dump truck has a variety of configurations, the following for you to introduce the common several:

1. Shaanxi Chengli 6X4 construction truck
   • Power System: Equipped with Weichai WP10.290 engine, the maximum horsepower is 290, which meets the National III emission standard, and with Fast 9JS135 transmission, the head speed ratio is 12.11.
   • Chassis: Steyr 16 ton rear axle, speed ratio 5.735.
   • Container Size: 5600*2300*1100mm.
2. Chengli Xiongshi 6X4 electric dump truck
   • 270 HP model: Equipped with Yuchai engine, National Five emission standard, 10-speed transmission, 6.8 meters long cargo box.
   • 300 HP model: equipped with Weichai engine, National Five emission standard, 10-speed transmission, 5.6 meters long cargo box.
3. Dongfeng 6X4 Dump Truck
   • Powertrain: Choose between Yuchai Kuo VI 245hp or 270hp engine, coupled with Faster 10-speed transmission.
   • Chassis part: Dongfeng Dana rear axle, speed ratio is optional 5.13 or 5.92, 5.5 tons front axle with multiple spring design, wheelbase is 3300mm+1350mm.
   • Box size: 4.5m, 4.6m, 4.7m, 4.8m, 5m boxes.
4. Cheng Li Dump Truck
   • Engine: Yuchai 270 HP, Yuchai 350 HP and Weichai 300 HP.
   • Rear Axle: can choose 10 tons, 13 tons and 16 tons, the rear axle box can choose between 5 meters and 6 meters 2.
